55
GB MT
2. Then trap the end of each thread in one
of the grooves (61) on the spool (53).
Pull the threads tight and ensure that
they are parallel in the two thread
channels. In addition, the thread spool must
not be lled with more than 3 m of thread
in each channel, as otherwise the automatic
thread mechanism will not function correctly.
Lubricating the gears
The gears require lubrication after around
10 hours of operation.
Fig.
:
1. Loosen the screw (62) on the gears us-
ing the large 5 mm Allen key (32).
2. Insert around 5 g of commercially-avail-
able lubricating grease into the lubrica-
tion opening on the gearbox housing.
3. Close the gears again using the screw
(62).
Adjusting the Carburettor
The carburettor is preset in the factory for
optimal performance. If subsequent adjust-
ments are required, have them carried out
by a specialist workshop.
Removing blockages
Switch the device off and
remove the spark plug
connector (
1) before you work
on the cutting unit.
Wear protective gloves in order to
avoid cutting yourself.
Maintenance Intervals
Regularly carry out the maintenance work
listed in the “maintenance intervals” table.
Regular maintenance prolongs the life
of the equipment. It also gives optimum
cutting performance and avoids accidents.
Table “Maintenance Intervals”
Machine Part Action
Before
Each Use
Operating Hours
10 20
Screws, nuts, bolts Check, tighten
Air lter Clean or replace
Fuel lter Replace
Spark plug Clean/adjust/replace
Fuel hoses Check, replace if necessary
Complete machine Check, clean if necessary
Operating handle Check for function
Cutting head Check correct installation
Coupling
Check that the device is sta-
tionary when idling
Lubricating the gears
