22
Please note the information on saw blade
types.
Any other use that is not expressly permit-
ted in this instruction manual may pose
a serious hazard to the user and result in
damage to the device. The operator or
user of the machine is responsible for any
accidents or personal injury and/or mater-
ial damage to third parties or their prop-
erty. The machine is intended to be used
by do-it-yourselfers. It was not designed
for heavy commercial use. The warranty
is void in the case of commercial use. The
manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Jigsaw
• 1 Wood saw blade T144D HCS,
Swiss made
• 1 Hex key
• Splinter guard (pre-assembled)
• Slide shoe (pre-assembled)
• Guard cover (pre-assembled)
• Suction nozzle (pre-assembled)
• Reducer piece
• Parallel guide
• Translation of the original instructions
Overview
The illustrations for the
device can be found on
the front and back fold-out
page.
1Rotary wheel
2Lock button
3On/Off switch
4Handle (Insulated gripping surface)
5Hex key
6Holder (Hex key)
7Power cord
8Reducer piece
9Suction nozzle
10Notch
11Slide shoe
12Switch (dust blower function)
13Footplate
14Hexagon socket screw
15Pendulum stroke switch
16Guide roller
17Wood saw blade
18Mount (Parallel guide)
19Retaining screw
20Guard cover
21Chuck
22LED work light (not visible)
23Release (Chuck)
24Button (LED work light)
25Splinter guard
26Recess in slide shoe
27Parallel guide
Description of functions
With the jigsaw, the saw blade clamped
on one side cuts via a stroke movement.
With the pendulum stroke, the guide roller
moves the saw blade forwards during
every upstroke in addition to the vertical
saw movement.
Please refer to the descriptions below for
information on how the operating ele-
ments work.
