PARKZONE P-47 Thunderbolt - Table of Contents

3
EN
To register your product online, visit www.parkzone.com
Thunderbolt Specications
Wingspan 42.2 in (1070mm)
Length 36.9 in (940mm)
Weight (RTF)
40.0 oz (1130 g)
42.5oz(1200 g) with retracts and flap servos
Center of Gravity 60.0mm (±2mm) from leading edge at wing root
Table of Contents
TheP-47Thunderbolt,“TheJug”,wasoneofthefastestandlargestsingle-engineUSghtersduringWorldWarII.Witheight.50-calibermachinegunsand
heavyarmor,theThunderboltcouldgiveandtaketremendousdamageandstillbringitspilothomesafe.TheThunderboltwasusedinabouteverytypeof
mission,fromdogghtingtobomber,toescortandgroundattack,theP-47coulddoitall.Fromthetrimschemeofthe404thFighterGroup,tothedummy
radialengine,.50calibergunbarrels,scaleairexitsthroughtheturbochargerexhaustandintercoolerdoorsanddetailedcockpitarea,ParkZonebringsthis
famous fighter to life loaded with scale detail.
Note: Not all wiring is shown
®
