PARKZONE P-47 Thunderbolt - Aircraft Setup and Operation; Control Linkage, CG, and Prep

7
EN
Tip:Turntheclevisclockwiseorcounterclockwiseontheconnector.Make
suretransmittertrimsarecenteredbeforemakingthisadjustment.
• Pulltheelasticbandfromtheclevistotheconnector.
• Carefullyspreadtheclevisandputtheclevispininaselectedholeinthe
control horn.
• Movetheelasticbandtoholdtheclevisonthecontrolhorn.
Installing Clevises on Control Horns
1.
4.
5.
6.
2.
3.
Note: Not to scale
Factory Settings
Note: Not to scale.
Note: Not to scale.
Rudder
Tail
Wheel
Arms Horns
Aileron
Flap
Elevator
Arms
Horns
Installbatteryallthewayforwardinthefuselageusingthehookand
loop strap. Turn the model until landing gear faces up to find balance
most easily.
Adjusting Center of Gravity (CG)
60mm (2.35 in) ± 2mm from
leading edge of the wing at
the fuselage
First Flight Preparation
• Removeandinspectcontents
• Readthisinstructionmanualthoroughly
• Bindaircrafttoyourtransmitter
• Installtheightbatteryintheaircraft(onceithasbeenfullycharged)
• Makesureconnectorsmovefreely
• PerformtheControlDirectionTestwiththetransmitter
• Adjustightcontrolsandtransmitter
• Adjustbatteryforcenterofgravity(CG)
• PerformaradiosystemRangeCheck
• Findasafeandopenarea
• Planightforyingeldconditions
Maintenance After Flying
• DisconnectightbatteryfromESC(RequiredforSafety)
• Turnofftransmitter
• Removeightbatteryfromaircraft
• Rechargeightbattery
• Repairorreplacealldamagedparts
• Storeightbatteryapartfromaircraftandmonitorthebatterycharge
• Makenoteofightconditionsandightplanresults,
planning for future flights
