PARKZONE P-47 Thunderbolt - Binding and Pre-Flight Setup; Transmitter and Receiver Binding Process; Pre-Flight Preparation Checklist; Receiver and Battery Installation

5
EN

Binding Procedure Reference Table
1. Readtransmitterinstructionsforbindingtoareceiver(locationoftransmitter’sBindcontrol).
2. Makesuretransmitterispoweredoff.
3. Install a bind plug in the receiver bind port.
4. ConnecttheightbatterytotheESC.ThereceiverLEDwillbegintoashrapidly.
5. Movethetransmittercontrolstoneutral(ightcontrols:rudder,elevatorsandailerons)ortolowpositions
(throttle,throttletrim,andightcontroltrims).*
6. Poweronthetransmitterwhileholdingthetransmitterbindbuttonorswitch.Refertoyourtransmitter’smanualforbindingbuttonorswitch
instructions.
7. Whenthereceiverbindstothetransmitter,thelightonthereceiverwillbesolidandtheESCwillproduceaseriesofsounds.
Theseriesofsoundsisalongtone,then3shorttonesthatconrmtheLVCissetfortheESC.
8. Remove the bind plug from the receiver in the battery compartment.
9. Safelystorethebindplug(someownersattachthebindplugtotheirtransmitterusingtwo-partloopsandclips).
10. Thereceivershouldkeepthebindingtothetransmitteruntilanotherbindingisdone.
*Thethrottlewillnotarmifthetransmitter’sthrottlecontrolisnotputatthelowestposition.
If you encounter problems, obey binding instructions and refer to transmitter troubleshooting guide for other instructions. If needed, contact the ap-
propriateHorizonProductSupportofce.
BindingistheprocessofprogrammingthereceiverofthecontrolunittorecognizetheGUID(GloballyUniqueIdentier)codeofasinglespecictransmitter.You
needto‘bind’yourchosenSpektrum™DSM2technologyequippedaircrafttransmittertothereceiverforproperoperation.
Note: Any JR
®
orSpektrumfullrangeDSM2™transmittercanbindtotheSpektrumAR600re-
ceiver. Please visit www.bindnfly.com for a complete list of compatible transmitters.
Transmitter and Receiver Binding
Note:WhenusingaFutabatransmitterwithaSpektrumDSM2module,youmustreversethethrottlechannel.
Note: Always disconnect the Li-Po from the receiver of the aircraft when not flying. Failure to do so will render the battery unusable.
Before Flight
CAUTION:Whenarmed,themotorwillturnthepropellerinresponsetoanythrottlemovement.
Whentheaircraftdoesnotrespond,bindingorrebindingmayberequired.
1
4
Continuous LED
Series of tones
2
3
Install flight battery in battery cavity.
Secure flight battery with hook and
loop strap.
Remove battery hatch
from nose of aircraft.
Lower throttle and throttle
trim to lowest settings.
Connect
battery to
ESC
Power on
transmitter
Wait 5
seconds
Installing a Receiver
Battery Selection and Installation
1.Installyourparkyerorfullrangereceiverinthefuselageusinghookand
loop tape or double-sided servo tape.
2. Attach the elevator and rudder servo connectors to the appropriate channels
of the receiver.
3.AttachtheaileronY-harnesstotheaileronchannelofthereceiver.
4.AttachtheESCconnectortothethrottlechannelofthereceiver.
1.WerecommendtheParkZone2200mAh11.1V25CLi-Pobattery(PKZ1029).
2. If using another battery, the battery must be at least a 25C 2200mAh battery.
3.Yourbatteryshouldbeapproximatelythesamecapacity,dimensionsand
weightastheParkZoneLi-Pobatterytotinthefuselagewithoutchanging
the center of gravity a large amount.
®
