5
1.2 General information
1.2.1Specification
Parameter
Items Data Items Data
Type of engine 4-stroke L Weight（S） 49Kg
Displacement 323cm
3
Weight（L） 51Kg
Bore X stroke 59mm×59mm Recommended fuel Unleaded regular gasoline
Gear ratio 2.08（27/13） fuel tank capacity 24L
Overall length 1001mm Recommended engine oil SAE10W30 orSAE10W40
Overall width 427mm Engine oil quantity 1.0L
Overall height（S） 1080mm Recommended gear oil Hypoid gear oil SAE﹟90
Overall height（L） 1207mm Gear oil quantity 250cm
3
Transom height (S) 381mm Spark plug DPR6EA-9
Transom height (L) 508mm Spark plug gap 0.8～0.9mm
Performance
Items data Items data
Maximum output
11Kw/5000Rpm(15HP)
Valve clearance IN
(cool engine)
0.15～0.25mm
7.3Kw/5000Rpm (9.9HP)
Valve clearance EX
(cold engine)
0.20～0.30mm
Full throttle operating
range
4500～5500Rpm
Tightening
torque for
engine
Spark plug 18.0Nm
Idling speed(in
neutral)
950±50Rpm
Engine oil
drain bolt
28.0Nm
