1. Main components and General information
1.1 Main components
2
1
5
4
3
6
8
7
9
10
11
12
15
14
13
16
17
20
19
18
21
1. Top cowling 9. Steering friction bolt 16. Throttle grip
2. Top cowling lock handle 10. Tiller handle 17. Clamp bolt
3. Drain screw 11. Starter handle 18. Rope attachment
4. Anti-cavitation plate 12. Warning indicator(s) 19. Tilt support bar
5. Propeller 13. Gear shift lever 20. Fuel joint
6. Cooling water inlet
14. Engine stop button/
21. Fuel tank
7. Trim rod
Engine stop lanyard switch
8. Clamp bracket 15. Throttle friction adjuster
