The outboard motor should be trailed and stored in the normal running position. If there is insufficient road
clearance in this position, then trailer the outboard motor in the tilt position using a motor support device.
CAUTION:
Do not use the tilt support lever or knob when trailering the boat. The outboard motor could shake
loose from the tilt support and fall.
WARNING:
Never get under the lower unit while it is tilted, even if a motor support bar is used.
When transporting or storing the outboard motor while removed from a boat, keep the outboard
motor in the attitude shown.
figure 1 figure 2 figure 3
Note:
Place a towel or something similar under the outboard motor to protect it from damage when
as shown in the figure 2 or figure 3 above.
Please make sure the tiller handle faces down to make the throttle handle point to the direction
of propeller.
41
