5
1.2 General information
1.2.1Specification
Main technical data:
Items Data Items Data
Type of engine Three cylinders,4-stroke Weight(BWL-D-EFI/BWS-D-EFI) 101.5Kg/99.9Kg
Displacement 747cm
3
Weight(FWL-T-EFI/FWS-T-EFI) 102.1Kg/100.5Kg
Bore X stroke 65mm×75mm Recommended fuel Unleaded regular gasoline
Gear ratio 2.0（26/13） Fuel tank capacity 24L
Overall length
1173mm(BM/BW)
768mm(FW)
Recommended engine oil SAE10W30 or SAE10W40
Overall width
426mm(BM/BW)
410mm(FW)
Engine oil quantity 1.7L(with oil filter)
Overall height 1361mm (S) /1234mm(L) Recommended gear oil Hypoid gear oil SAE﹟90
Transom height 381mm(S)/508mm(L)
Gear oil quantity 430cm
3
Weight (BML/BMS) 94Kg/92.4Kg
Spark plug DPR7EA-9
Weight (BWL/BWS) 97.5Kg/95.9kg Spark plug gap 0.8~0.9mm
Weight(FWL/FWS) 96.6Kg/95Kg
