Parsun F30 BM User Manual

1
1. Main components and General information
1.1 Main components
1.Top cowling 8. Tilt & trim rod 15.Throttle frication adjuster
2.Top cowling lock handle 9. Clamp bracket 16.Throttle grip
3.Drain screw 10.Tilt & trim button 17.Clam bolt
4.Anti-cavitation plate 11.Tiller handle 18.Stand bar
5.Trim-tab 12.Starters handle 19.Tilt lock bar
6.Propeller 13.Shifting handle 20. Fuel tank
7.Cooling water inlet 14.Engine stop button and switch 21.Remote control box
