3. Throttle indicator
The throttle indicator is on the throttle grip. The fuel consumption curve on the throttle indicator shows
the relative amount of fuel consumed for each throttle position. Choose the setting that offers the best
performance and fuel economy for the desired operation.
1. Throttle indicator
4. Throttle friction adjuster
The throttle friction adjuster is on the tiller handle, which provides adjustable resistance to movement of
the throttle grip, and can be set according to operator preference. To increase resistance, turn the
adjuster clockwise. To decrease resistance, turn the adjuster counterclockwise. When constant speed
is desired, tighten the adjuster to maintain the desired throttle setting.
