10 – English
WHAT IS WHAT?
1. Engagement rollers
2. Support rollers
3. Drive disc
4. Lock nuts for support rollers
5. Water flow adjustment valve
6. Choke
7. Stop switch
8. Starter throttle catch
9. Fuel tank
10. Water cooling connection
11. Engagement roller knobs
12. Blade guard/splash guard
13. Lock button for drive disc
14. Ring blade
What is what on a power cutter?
15. Support cover screws
16. Roller adjustment screws
17. Decompression valve
18. Air filter cover
19. Starter handle
20. Throttle trigger lockout
21. Throttle
22. 6 mm T-allen wrench
23. 4 mm T-allen wrench
24. 19 mm Spanner
25. Combination spanner
26. Operator’s manual
27. Warning decal
28. Type plate
9
2
2
3
1
1
4
5
27
6
7
8
28
21
20
19
18
17
15
15
16
12
11
13
12
14
11
10
26
25
23
24
22
