English – 23
TECHNICAL DATA
Blade Diameter 350 mm (14")
Cutting Depth 260 mm (10")
Motor Speed, maximum 10 100 rpm
Weight, Cutting Blade 0,8 kg (1,8 lbs)
Dimensions: Height 410 mm (16")
Length 715 mm (28")
Width 260 mm (10")
Water Requirement 4 lit/min (1 gallon/min)
Cutting equipment
Cutting blade Max. peripherical speed
14" (350 mm) 55 m/s
Engine
Cylinder volume, cm
3/
cu.in 93,6/5,7
Cylinder bore, mm/inch ∅ 56/2,2"
Stroke, mm/inch 38/1,5"
Idle speed, rpm 2 500 rpm
Recommended max.
speed, unloaded, rpm 9 800 ± 300
Power, kW 4,5
Ignition system
Manufacturer FHP
Type of ignition system CD
Spark plug Champion RCJ-7Y
Electrode gap, mm/inch 0,5 (.020")
Fuel and lubrication system
Manufacturer Tillotson
Carburetor type HS 282A
Fuel capacity, litre/US Pint 1,0/2,65
Weight
Without fuel and cutting blade, kg/Lbs 13,1 kg/28.9 Lbs
Noise emissions
(see note 1)
Sound power level, measured dB(A) 117
Sound power level, guaranteed L
WA
dB(A) 118
Sound levels
(see note 2)
Equivalent sound pressure level at
the user’s ear, measured according to EN 1454 , dB(A). 103,5
Vibration levels
Handle vibrations measured according to EN 1454 m/s
2
.
Front handle, idling, m/s
2
7,7
Front handle, full speed, m/s
2
2,8
Rear handle, idling, m/s
2
11,8
Rear handle, full speed, m/s
2
7,5
Note 1: Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive 2000/14/EC.
Note 2: Equivalent sound pressure level is calculated as the time-weighted energy total for sound pressure levels under various
working conditions with the following time distribution: 1/2 idling and 1/2 max speed.
K950 Ring
