3) Interface signal definition
No.
Signal
Functions
1 FG Frame Ground
2 DRAWER 1 Cash drawer 1 driving signal
3
DRSW Cash drawer status detection signal
4 VDR Cash drawer driving power
5 DRAWER 2 Cash drawer 2 driving signal
6
GND Circuit share ground
Table 6.7-1Cash drawer interface definition
Caution:
Do not connect or disconnect communication cable plug when the printer is powered on;
Communication cable should be far away from strong current;
Communication cable should adopt shielded cable.
