RP-700User’s Manual
Paper thickness 0.06mm~0.10mm thermal paper
Power
supply
Input 100-240VAC, 50-60Hz
Output 24V ± 5% DC, average current 2A
External or not External power adapter
Human-machine
interface
Power switch Support
Button Support
LED Support, including POWER LED and ERROR LED
Buzzer Support, 24V buzzer
Reliability
Lifetime of print head ≥150Km (standard test sample with 12.5% duty ratio)
Lifetime of cutter 2,000,000 cuts (standard test condition)
MCBF 70,000,000 lines
MTBF 360,000 hours (main control board)
Operation temperature and humidity
5°C～ 45°C，20%～
90%RH(40°C)
Storage temperature and humidity
-40°C～60°C， 10%～
90%RH(40°C)
Overall dimensions 127mm(L)*127mm(W)*134mm(H)
Functions
Saving paper Support
Button configuration Support (configure the printer without computer)
Right-up-side printing Support
Water mark printing Support
Gray scale printing Support
Table 2.1-1 Technical specifications
2.2 Cutter parameters
Item
Parameter
Remarks
Cutting method Sliding blade
Cutting time
500ms The time of one cut
Cutting interval 3s 20 cuts/minute (Max.)
Applicable paper types 0.06mm~0.10mm thermal paper
Operation voltage 24VDC
Max. operation current 1.2A Operation voltage 24VDC
Cutter lifetime 2,000,000 cuts Standard test condition
Table 2.2-1 Technical parameters of cutter
2.3 Paper specification
2.3.1 Parameters of continuous paper
 Paper type: thermal paper
 Paper supply mode: paper roll
 Paper width: 57.5/80/82.5mm
 Paper thickness: 0.06mm-0.10mm
 Thermal layer: outward
- 3 -
