Parweld XTM 201i - Safety Precautions; Technical Specifications; Description of Controls; Installation

www.parweld.co.uk www.parweld.co.uk
3
Contents
Page
1.0 Safety Precautions 4-5
2.0 Product Description 5
3.0 Technical Specications 5
4.0 Description of controls 6
5.0 Installation 7
5.1 Unpacking the machine 7
5.2 Location 7
5.3 Input and grounding connection 7
5.4 MIG welding torch setup 7
5.4.1 Changing Feed Rolls 7
5.4.2 Welding wire installation 7
5.4.3 Torch installation 7
5.4.4 Work return lead connection 8
5.4.5 Shielding gas connection 8
6.0 Operation 8-9
6.1 MIG welding (Synergic and Manual) 8
6.1.1 Feeding wire electrode 8
6.1.2 Optimising weld parameters (Manual) 9
6.1.3 Optimising weld parameters (Synergic) 9
6.1.4 Burn Back 9
6.2 MMA Welding 9
6.2.1 Torch installation 9
6.2.2 Work return lead connection 9
6.2.3 Operation 9
6.3 TIG Welding Operation 9
7.0 Fault Finding 10-12
8.0 Accessories 12
8.1 Feed Rolls 12
8.2 Torch Spares 12
8.3 Gas Equipment 12
8.4 Flow Meters 12
9.0 Torch Schematic ECO-GRIP MAX 150A 13
10.0 EC Declaration of Conformity 14
10.1 RoHS Compliance Declaration 14
10.2 WEEE Statement 15
10.3 Statement of Warranty 15
