Inserting
£
1. PRESS UP
£
1. CLOSE OVER
2. PULL OUT
£
2. PRESS DOWN
£
B. Lift the fuel cell
adaptor and insert the fuel cell into
the tool.
C. Release the adapter so it is centered on the fuel cell.
A.
When loading a fuel cell,
lift the tool off of the
work
surface so the work contact element (WCE) is not depres-
sed. Press forward at the back of the actuator cover and
pivot outward to open. The cover will swing out of the way.
D. Close the actuator cover over the fuel valve/cylinder
assembly. Push forward and down until the actuator
cover snaps into position to complete the loading of fuel
in the Impulse Bradder.
Fuel Cell
Fuel Cell
™
™
