Paslode IM200Li.2 - User Manual

Questions and Answers

A
Alejandro SmithAug 12, 2025
Why Paslode Nail Gun fasteners not driving fully?
- E
  Erin MitchellAug 12, 2025
  If your Paslode Nail Gun is operating correctly, but the fasteners aren't driving fully, it could be due to a few reasons. The work-contacting element might need adjustment, so try adjusting it. Also, the fuel cell could be low; check it and replace it if necessary. Finally, there might be a loss of seal in the combustion chamber. To check for a leak, press the work-contacting element against the workpiece for one minute, then pull the trigger. If the fastener still doesn't drive, there's likely a leak that requires professional service.
J
Jenna GarciaAug 16, 2025
Why Paslode IM200Li.2 Nail Gun operates but no fastener is driven?
- C
  Caroline MullinsAug 16, 2025
  If your Paslode Nail Gun operates but doesn't drive any fasteners, consider these potential causes: You might be using the wrong type of fasteners, so ensure you're using fasteners that meet Paslode specifications. Also, check that the follower is properly engaged behind the fastener strip. Finally, there may be a jammed fastener; clear the jam to resolve the issue.
E
Edward SmithAug 20, 2025
Why Paslode IM200Li.2 battery does not accept charge?
- T
  Theresa MasonAug 20, 2025
  If the Paslode Nail Gun battery doesn't seem to accept a charge when plugged into the charger, it could be due to a few reasons. The indicator lights on the charger might be inoperative, or the charger itself could be defective. Try the battery in the tool after a full charge cycle. If the tool's indicator light is red, the charger isn't working properly, so replace it or monitor the charging time to ensure the battery has adequate time for recharging. It's also normal for the battery to feel warm after properly charging. Another possibility is that the battery is damaged or its cycle life is exhausted, in which case you should replace the battery.
N
Nicholas TorresAug 23, 2025
What to do if Paslode IM200Li.2 Nail Gun driver blade did not return to up position?
- T
  Thomas PriceAug 23, 2025
  If your Paslode Nail Gun operated and drove fasteners, but the driver blade didn't return to the up position, it could be caused by built-up dirt and debris on the driver blade or in the nosebore. Clean the driver blade and nose bore with a degreaser cleaner. The tool might also just be dirty, so try cleaning it.
E
Eric HernandezAug 27, 2025
Why Paslode Nail Gun fasteners are over or under-driven?
- M
  Michael BaileyAug 27, 2025
  If your Paslode Nail Gun is sometimes over-driving and sometimes under-driving fasteners, the work-contacting element is likely not adjusted properly for the material you're fastening. Adjust the work-contacting element and readjust it as needed when the material density or thickness changes.
M
mendozastephanieAug 31, 2025
What to do if Paslode Nail Gun work-contacting element does not depress fully?
- A
  Allison CarterAug 31, 2025
  If the work-contacting element on your Paslode Nail Gun doesn't depress fully and the tool won't operate, it could be due to a bent work-contacting element or debris in the track. Remove and inspect the lower probe, clean the track, and repair or replace the lower probe as needed. Also, check if the lockout feature is engaged; if so, add a strip of nails.
C
carolyncrossSep 3, 2025
What to do if Paslode IM200Li.2 Nail Gun charger gets hot?
- K
  Kimberly HallSep 3, 2025
  If your Paslode Nail Gun charger gets hot, makes excessively loud noises, or smokes during the charging cycle, discontinue use immediately and unplug it from the power source. Replace the charger, and tag or dispose of the old charger to prevent accidental reuse.
T
tgraySep 7, 2025
Why Paslode IM200Li.2 Nail Gun combustion chamber does not drop?
- D
  Deanna RothSep 7, 2025
  If the combustion chamber of your Paslode Nail Gun doesn't drop after the tool cycles, it could be because the work-contacting element is bent or dirty. Clean the track or replace the work-contacting element.

Summary

Introduction and Warranty

Tool Operation Overview

Introduces the Paslode Cordless Brad Nailer and its operation.

Warranty Details and Statement

Covers limited warranties, terms, and exclusions.

Overview of Paslode Cordless Brad Nailer

Tool Description and Specifications

Explains the tool's features and lists technical specs.

Major Component Assemblies

Identifies and describes Handle, Motor, and Magazine assemblies.

Safety Instructions

Fire, Explosion, and Environmental Hazards

Warns about flammable materials, high temperatures, and ventilation.

General Handling and Injury Prevention

Covers reading manuals, tool handling, and avoiding misuse.

Safe Operating Procedures

Trigger, Work Contacting Element, and Fastener Safety

Details safe trigger use, WCE operation, and fastener handling.

Jam Clearing and Malfunctioning Tools

Provides instructions for clearing jams and handling faulty tools.

Safety Precautions and Storage

Hazard Avoidance and Location Safety

Covers avoiding hazards like concealed wiring and safe work on heights.

Operator Qualification and Battery Disposal

Emphasizes qualified operators and proper battery recycling.

Battery and Charging System

System Overview

Introduces the rechargeable battery and charging system.

Charging Procedures and Times

Details how to charge the battery and typical charging durations.

Charging Precautions

Lists practices to avoid during battery charging.

Battery Insertion and Indicator Light

Battery Indicator Light Function

Explains the function and colors of the battery indicator light.

Inserting and Disengaging Battery

Step-by-step instructions for inserting and removing the battery.

Fuel Cartridge Information

Fuel Cartridge Description and Operation

Explains the internal structure and function of the fuel cartridge.

Fuel Cartridge Safety and Handling

Warns about hazards and provides safe handling/storage instructions.

Fuel Cartridge Management

Best Use Date and Disposal

Advises on using fuel cartridges before the expiry date and proper disposal.

Inserting Fuel Cartridge

Step-by-Step Loading Procedure

Provides illustrated steps for loading a fuel cartridge into the tool.

Preparing the Nailer for Use

Fasteners and Loading

Discusses recommended fasteners, loading procedures, and weather considerations.

Weather Operation Guidelines

Provides recommendations for operating the tool in hot and cold weather.

Paslode Cordless Brad Nailer Operation

Operating the Tool

Details the sequence of actions for operating the nailer, including WCE and trigger.

Depth of Drive Adjustment

Explains how to adjust the depth of drive for fasteners.

Fasteners and Applications

Nailer Applications

Lists various applications for the 18 ga. Brad Nailer.

Compatible Fasteners and Part Numbers

Details Paslode 18 Gauge Brad Nails, part numbers, lengths, and applications.

Servicing Procedures

Field Serviceable Items

Lists procedures that users can perform, like checking battery and fuel cell.

Fuel Cell and Battery Checks

Explains how to check the fuel cell status and battery charge.

Clearing Jams and Tool Cleaning

Provides instructions for clearing fastener jams and general tool cleaning.

Tool Maintenance and Routine

Air Filter Maintenance

Instructions for cleaning and maintaining the tool's air filter.

End-of-Workday Routine

Steps to perform at the end of the workday for safety and efficiency.

Paslode Cordless Tool Accessories

Lists available accessories for the Paslode Cordless 18 ga. Brad Nailer.

Troubleshooting Guide

Battery and Charger Problems

Diagnoses and resolves common issues with the battery and charger.

Normal Operation Issues

Addresses common problems encountered during normal tool operation.

Troubleshooting Operational Faults

Fastener Drive and Sealing Issues

Resolves problems with fastener depth, sealing, and driving.

Tool Operation and Component Faults

Addresses issues like wrong fasteners, jammed fasteners, and dirty components.

Paslode IM200Li.2 Specifications

General

Battery Type	Lithium-ion
Voltage	7.4V
Fuel Cell Capacity	1000 shots
Fastener Gauge	16 gauge
Operating Pressure	Not applicable (gas-powered)
Firing Mode	Sequential
