Paslode PS225C - Tool and Fastener Specifications

3
TOOL SPECIFICATIONS
MODEL NO. PS225C (Part# 515900)
HEIGHT
12 5/8”
WIDTH
LENGTH 11"
WEIGHT 4 lbs. 5 oz.
OPERATING PRESSURE 80 to 120 psi (5.5 to 8.3 bar)
FASTENER SPECIFICATIONS
TOOL AIR FITTINGS:
This tool uses a 1/4” N.P.T. male plug. The fitting must be capable of discharging
tool air pressure when disconnected from the air supply.
OPERATING AIR PRESSURE:
80 to120 psi (5.5 to 8.3 bar). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
NAIL LENGTH
1 1/4” - 2 1/2”
SHANK DIAMETER .080 -.105”
TOOL AND FASTENER SPECIFICATIONS
NAIL COATINGS
Electro-Galvanized, Aluminum,
Hot Dipped Galvanized, Stainless Steel
MAGAZINE TYPE
0 Degree, Plastic Coil
5 3/4”
