Page 62
12. CHANGE FROM NET TO GROSS WEIGHT
Master: <Addr> “CL” EOT
DA
T 1400: <Addr> “C” ACK EOT or <Addr> NAK EOT
13. DELETE TARE COMMAND
MASTER: <Addr> “DT” EOT
DA
T 1400: <Addr> “D” ACK EOT or <Addr> NAK EOT
14. REQUEST FOR NET WEIGHT (used for repeater program PDAT06)
MASTER: <Addr> “W” “N” EOT
DA
T 1400: <Addr> “W” <rip status> <net> ETX <csum> EOT or <Addr> NAK EOT
15. REQUEST FOR GROSS WEIGHT (used for repeater program PDAT06)
MASTER: <Addr> “W” “G” EOT
DA
T 1400: <Addr> “W” <rip status> <gross> ETX <csum> EOT or <Addr> NAK EOT
where:
<rip status>: character encoded as per the following table (bit = 1 in case of true condiction).
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 1 1
Displayed weight
0 = net
1 = gross
Zero
band
Stable
weight
Zero
center
<net> <gross> = field consisting of 8 ASCII characters with the net and gross weight value justified to
the right (without insignificant zeroes, with decimal points and negative signs).
In overweight conditions the field assumes the value: “^^^^^^^^”.
In conditions of underweight (negative weight greather of 999999), the field assumes the value: “_ _ _ _”.
Under weight reading error conditions, the field assumes the value: “ O-L ”.
