PAX D200 User Manual

2. Installation
1） SAM Card Installation
① Open up battery cover, which is at the bottom of the terminal;
② Take out battery;
③ Insert SAM card to corresponding SAM card slot.
2） Battery Installation
① Hold the battery with its facing up;
② Attach battery forelock to battery bayonet;
③ Press down the other side of the battery
3. Instruction
1） Power ON/OFF
Power on: Insert power adapter or insert the battery, Press button for 3 seconds until LED
backlight is on. If POS terminal is being turned on successfully, PAX LOGO can be seen and
‘Di’ from the buzzer can be heard.
Power off: Press button for 3 seconds until Shutting down... can be seen. POS terminal is
being turned off.
2） Magnetic Stripe Card
When user swipes magnetic stripe card along the slot, the backside of card, which contains
magnetic strip information, should be facing to the terminal. Bi-directional swiping is supported. It
is recommended to swipe starting from the top of the terminal to the bottom of the terminal with a
constant moving speed.
3） IC card
When user insert IC card into the IC slot, the chip of IC card should be facing up; user is
recommended to gently insert the card, in order to avoid any physical damage to the card or the IC
slot of the terminal. If IC card is successfully read by the terminal, the IC card icon will be shown
on LCD display screen.
4. Specifications
Default
Contactless Card Reader
CPU： 32-bit，MIPS
Memory：32MB SDRAM , 32MB NOR Flash
Display：2.4 -inch 240x320 pixel color TFT LCD；LED backlight；
Keypad：10 alphanumeric keys, 5 functional keys，touch key;
Magnetic Card Reader ：Track 1/2/3，bi-directional swipe
IC Card Reader：1 user card （EMV2000）
SAM slots：SAM slot

1
Communication：Bluetooth, WIFI
Peripheral Ports: 1 Micro USB(Device)
1 Mini USB(RS232)
Power Supply：Input：100—240VAC ~0.2A 50/60HZ
Output：5V DC 1A
Battery：Li-on bttery,1900mAh,3.7V
Working Environment： Temperature：0 ℃~50℃(32℉~122℉)
