PAGE 6
The reader's default indication has all the LED's on. Access granted is denoted with a single ashing Green LED.
Access Denied is a single ashing Red LED.
Each time the unit is powered on, it will run an internal health check. During this phase (about 5 secs) the OK
LED will ash quickly before changing to a slower heartbeat.
The Net2 ACU is designed to take input from Clock and Data readers through its two (In/Out) reader ports.
It can also be congured for Wiegand (26 / 50 bits).
It has an RS485 communications port that is used for uploading rmw
are and user information as well as
providing Event information to the PC.
Wire the components to the Access Control Unit (ACU) as shown on the rst page.
Press the exit button or in the absence of an exit button short the 0V and exit terminals to test the relay
function. The lock Relay LED will come on and the lock should release.
Following the completed installation of this equipment, no further maintenance or testing is required.
It is advisable to ensure that any third party backup power supplies or recovery procedures are checked
regularly to ensure that the operation of the Paxton system is not compromised.
Maintenance
Ensure that all the LED's are lit on the reader/keypad.
Test each reader by presenting a token and the unit should beep and display a single ashing red or green LED.
Present a token at each reader. An event for each read should appear in the Events screen.
Change the default password for the System Engineer.
Set up other operators if required.
Set up time zones.
Set up access levels.
Users can be added & assigned to the required access level.
Departments can be created if required.
The Net2 CD can assist here with detailed application notes for setting up users and general system operation.
System checks
Installation and test
1 - Short circuiting, mutilation or incineration of the cells must be avoided to prevent one or more of the following
occurrences; Release of toxic materials, release of hydrogen and/or oxygen gas, rise in surface temperature.
2 - If a cell has leaked or vented the control unit must be replaced. The battery is not to be replaced.
