2
Motherboard User’s Guide
Memory Support
• Two 240-pin DIMM slots for DDR2 SDRAM memory modules
• Supports Dual Channel DDR2 800/667/533/400 memory bus
• Maximum installed memory is 16* GB
(* Duo to the DRAM maximum size is 2 GB at present, the memory
maximum size we have tested is 4 GB.)
Expansion Slots
• One PCI Express x16 slot (MCP61S only supports PCI Express x8)
• One PCI Express x1 slot
• Two 32-bit PCI slots
Onboard IDE channels
• One IDE Connector
• Supports PIO (Programmable Input/Output) and DMA (Direct Memory
Access) modes
• Supports IDE Ultra DMA bus mastering with transfer rates of 133/100/66/
33 MB/sec
Serial ATA
• Four Serial ATA Connectors
• Compliant with the SATA2 with 3.0 Gb/s per direction per channel
• 7.1+2 Channel High Definition Audio Codec
• All DACs support 192K/96K/48K/44.1KHz DAC sample rate
• Software selectable 2.5V/3.75V VREPOUT
• Meets Microsoft WHQL/WLP 2.x audio requirements
• Direct Sound 3D
TM
compatible
7.1 Channel High Definition Audio Codec
ADC support 148K/96K sample rate
High quality differential CD input
Power Support: Digital: 3.3V; Analog: 5.0V
Meets Microsoft WHQL/WLP 2.0 audio requirements
Direct Sound 3D
TM
compatible
5.1 Channel Hifh Definition Audio Codec
ADCs support 44.1/48k/96k sample rate
Meets Microsoft WHQL/WLP 3.0x audio requirements
Direct Sound 3D
TM
compatible
5.1 Channel Hifh Definition Audio Codec
ADCs support 44.1/48k/96k sample rate
Meets Microsoft WLP 3.08 Vista premium and mobile PCs audio
requirements
Direct Sound 3D
TM
compatible
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Audio Codec (optional)
