3
Chapter 1: Introduction
Fast Ethernet LAN
• 10Base-T/100BASE-TX IEEE 802.3u fast Ethernet transceiver
• Low-power mode
• MII and 7-wire serial interface
USB 2.0
• Compliant with Universal Serial Bus Specification Revision 2.0
• Compliant with Open Host Controller Interface Specification Revision 1.1
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
• Power management
• Wake-up alarms
• CPU parameters and memory timing
• CPU and memory timing
The firmware can also be used to set parameters for different processor clock
speeds.
Dimensions
• Micro-ATX form factor of 244 x 214 mm
Note: Hardware specifications and software items are subject to change without
notification.
• One LAN port
• Audio jacks for microphone, line-in and 6/8-channel (optional) line-out
Onboard I/O Ports
• Two PS/2 ports for mouse and keyboard
• One parallel port
• One serial port
• One VGA port
• Four back-panel USB2.0 ports
