67
L510010-03
C.C.
Figure 15-2 Fresh-Water Cooling System (5.0/5.7L)
WATER FLOW DIAGRAMS - 15
= RAW WATER FLOW
= FRESH WATER FLOW
To Cylinder
Block
To Cylinder
Block
From Intake
Manifold
= Drain Locations
