Peak 212 - Hydraulic System Fill and Tightening

18
2. Install toe guard.
N. Tighten all the hydraulic fittings, and fill the reservoir with hydraulic oil.
Note: In consideration of Power Unit’s durability and keep the equipment
running in the perfect condition, please use Hydraulic Oil 46#
Fig. 28
Fig. 29
Adjust the Moon gear
Locking the nuts after the moon gear
and arm lock engaged well
86
8
31
87
85
