General Controls
10
UM-NM30LA-MS Gas Generator
UM –NM30LA-MS
Nitrogen Pressure Gauge.
Air Inlet Fans.
Front View.
Elapsed Time Meter.
On/Off Switch.
1
0
Nitrogen Pressure
Nitrogen Generator
Nitrogen Outlet.
Serial Plate.
Mains Power IEC. Socket.
Drain Connection.
Air Outlet Fans.
OUTLET
DRAINSUPPLY DRAIN
Drain Connection.
