Peak NM30LA-MS - Technical Specification

6
UM-NM30LA-MS Gas Generator
UM –NM30LA-MS
169
(372.58)
Shipping Weight Kg
(lbs)
112.5
(248)
Weight Kg
(lbs)
60 x 67 x 94
(24 x 27 x 37)
Dimensions W x D x H cm
(inches)
General
Single Phase Power CordElectrical Connection
2.0 AmpsControl Circuit Breaker
8.0 AmpsCompressor Circuit Breaker
5.0 Amps@230V±10% ac (50/60Hz)
Electrical Requirements
0.01umParticles
60 minutesStart up time for Purity
30 Litres /min (ATP)Maximum Gas Outlet Flow
100 psig (6.8 barg)Maximum Gas Outlet Pressure
Outlet Gas
2000 MetersMaximum Altitude
70%Maximum Relative Humidity
30
o
C (86
o
F)Maximum Operating Ambient Temperature
5
o
C (41
o
F)Minimum Operating Ambient Temperature
Generator Environment
Technical Specification
