Peak NM30LA-MS - Unpacking and Installation and Connection

Connections
9
UM-NM30LA-MS Gas Generator
UM –NM30LA-MS
SUPPLY
DRAIN DRAIN
Rear View.
OUTLET
1 off 1/4" x 6mm Push-Fit (02-4331)
1 off 1/8" x 6mm Push-Fit (02-4330)
1 off 1/4" x 1/4" Compression Fitting (02-4421)
with White Teflon 1/4" Tubing (00-1266)
(04-1028-UK)
230Vac
(04-1038-EU)
(04-1029-US)
Power Cord
You will require Either.
your Instrument has at the inlet.
Depending on what connection
with Yellow Nylon 6mm Tubing (00-1306)
1 off 1/8" x 6mm Push-Fit (02-4330)
with Yellow Nylon 6mm Tubing (00-1306)
with White Teflon 6mm Tubing (00-1302)
