PCAN-USB Hub – User Manual
30
6 Technical Specifications
Connectors
Computer USB plug type A
CAN D-Sub (m), 9 pins
Pin assignment according to specification CiA® 303-1
RS-232 2 x D-Sub (m), 9 pins
USB 2 x USB socket type A
USB
Upstream port USB 2.0 (compatible to USB 1.1)
Downstream ports USB 2.0
CAN
Specification ISO 11898-2, High-speed CAN
2.0A (standard format) and 2.0B (extended format)
Bit rates 5 kbit/s - 1 Mbit/s
Controller NXP SJA1000
Transceiver NXP PCA82C251
Supplying external
devices
D-Sub Pin 1; 5 V, max 100 mA
External power supply:
D-Sub Pin 9; 9 - 36 V, max 2 A
Internal Termination none
RS-232
Transfer rates 0.3 - 120 kbit/s
Signal levels EIA-232E
Power Supply
Supply voltage 5 V DC via USB port (bus-powered operation)
9 - 36 V DC via Power socket (self-powered operation)
Power consumption At 5 V via USB port: max. 300 mA
At 12 V via Power socket: max. 150 mA
(each time without connected USB devices)
