PCAN-USB Hub – User Manual
34
Appendix C Quick Reference
Software/Hardware Installation under Windows
Install the driver from the supplied DVD, before you connect the
USB-Hub with the computer. The new hardware is detected at the
next Windows start and the driver is initialized.
Note: If you have no internet connection, install the serial driver
for the device via the product DVD:
Drivers/PCAN-USB Hub Serial Drivers/Windows/CMD
v2.xx.xx WHQL Certified.exe.
After the installation process for the CAN interface is finished
successfully the red CAN LED on the hub is illuminated. The RS-232
interfaces are accessible as virtual COM ports.
Getting Started under Windows
Run the CAN monitor PCAN-View from the Windows Start menu as
a sample application for accessing the CAN interface of the PCAN-
USB Hub. For initialization of the PCAN-USB Hub select the desired
CAN interface and the CAN bit rate.
LED Status Meaning
Green on Supply via upstream port Power
Red on external voltage supply
LED Status Meaning
Red on High-speed USB connection (USB 2.0) with a
computer
USB upstream
OFF Full-speed USB connection (USB 1.1) with a
computer
