27
AM On, Internal 1000Hz Source
AM On, External Source
Square Wave Pulse Width Adjustment Off
Square Wave Pulse Width Adjustment On and Output Positive Pulse
Square Wave Pulse Width Adjustment On and Output Negative Pulse
Note : The square wave pulse width adjustment on/off selection will show up in the sub function
only if the output select to square wave. If the pulse width adjustment is on, the pulse
width indicator will show up.
F R Q : 1 . 0 0 0 0 k H z
P W H O F F S B 4
F R Q : 1 . 0 0 0 0 k H z
P W H P o s S B 4
F R Q : 1 . 0 0 0 0 k H z
P W H N e g S B 4
To Next Page
