PeakTech 1245 User Manual

3.5. Rear Panel
Fig. 4 Rear Panel
1. The port of trigger signal output & Pass/Fail output
2. Handle
3. Air vents
4. Foot stool (can adjust the tilt angle of the oscilloscope)
5. Ground connection
-96-
1.
3.
2.
4. 5. 4.
