PeakTech 1245 - Horizontal System

Horizontal
System
Sampling rate range
P 1240
Dual CH 0.5 Sa/s ~ 250 MSa/s
Single CH 0.5 Sa/s ~ 500 MSa/s
P 1245
Dual CH 0.5 Sa/s ~ 500 MSa/s
Single CH 0.5 Sa/s ~ 1 GSa/s
P 1255
Dual CH 0.5 Sa/s ~ 1 GSa/s
Single CH 0.5 Sa/s ~ 2 GSa/s
P 1260
Dual CH 0.5 Sa/s ~ 1 GSa/s
Single CH 0.5 Sa/s ~ 2 GSa/s
P 1270
Dual CH 0.5 Sa/s ~ 1.25 GSa/s
Single CH 0.5 Sa/s ~ 2.5 GSa/s
P 1275
Dual CH 0.5 Sa/s ~ 1.6 GSa/s
Single CH 0.5 Sa/s ~ 3.2 GSa/s
Interpolation (sin x)/x
Max Record length
P 1240
Dual CH
≤Max
sampling rate
10M
Single CH
P 1245
Dual CH
≤Max
sampling rate
10M
Single CH
P 1255
Dual CH
≤500 MSa/s 10M
1 GSa/s 10K
Single CH
≤1 GSa/s 10M
2 GSa/s 10K
P 1260
Dual CH
≤500 MSa/s 10M
1 GSa/s 10K
Single CH
≤1 GSa/s 10M
2 GSa/s 10K
P 1270
Dual CH
≤500 MSa/s 10M
1 GSa/s
1.25 GSa/s
10K
Single CH
≤1 GSa/s 10M
2 GSa/s
2.5 GSa/s
10K
P 1275
Dual CH
≤400 MSa/s 10M
800 MSa/s
1.6 GSa/s
10K
Single CH
≤800 MSa/s 10M
1.6 GSa/s
3.2 GSa/s
10K
-168-
