3. Center the conductor within the transformer jaw, then
release the Meter slowly until the transformer jaw is
completely closed, Make sure the conductor to be tested is
placed at the center of the transformer jaw, otherwise it will
cause deviation. The Meter can only measure one conductor
at a time, to measure more than one conductor at a time will
cause deviation.
4. The double display shows the AC current True RMS value
and AC voltage True RMS value.
5. Press MAXMIN, the LCD displays , it starts recording
the maximum AC current True RMS value.
6. Press MAXMIN, the LCD displays , it starts recording the
minimum AC current True RMS value. Press MAXMIN,
again to show the present AC current True RMS value.
7. The display shows 0L when the current of the tested
conductor is higher than 1000A rms.
Note:
When the measurement has been completed, disconnect the
connection between the conductor under test and the jaw, and
remove the conductor away from the transformer jaw of the
Meter.
-44-
