Power input:
(47) AC Input:
External 16.5 Volt, 1 amp power supply should be plugged in at this point.
Plug the small jack at the end of the power supply lead into the 16 VAC socket
on the rear of the unit (47). Then plug the power supply provided with your
CD MIX 9072A into a main AC wall power receptacle.
CAUTION: Use only the power supply that is provided with this product. If the
original power supply must be replaced, consult your dealer or the factory for
assistance in obtaining the correct replacement. Failure to use the correct
power supply could result in fire or shock hazard, extensive circuit damage,
decreased performance, or non-operation.
+20dB
I I I IIIIII
I I I IIIIII
1
I
I ]
+10dB
OdB
-lOdB
-20dB
20 Hz 50
100
200
500 lk 2k Sk
10k 20k 40k
EQ Frequency and Gain Characteristics
10
