Peavey CS 1200 Owner's Manual

16
CS
®
1400/2000
Power Amplifiers
SPECIFICATIONS
CS 1400 CS 2000
Crosstalk
> -74 dB, “A” weighted referenced to
rated 4 ohm power
> -60 dB, “A” weighted referenced to
rated 4 ohm power
Current Draw @ 1/8 Power
745 watts @ 2 ohms, 505 watts @
4 ohms, 325 watts @ 8 ohms
1,090 watts @ 2 ohms, 745 watts
@ 4 ohms, 445 watts @ 8 ohms
Current Draw @ 1/3 Power
1,930 watts @ 2 ohms, 1,235 watts @
4 ohms, 815 watts @ 8 ohms
2,715 watts @ 2 ohms, 1765 watts
@ 4 ohms, 1,155 watts @ 8 ohms
Cooling
Two 80 mm DC fans, dual speed
operation
Two 80 mm DC fans, dual speed
operation
Controls
2 front panel attenuators, rear panel
mode switch, rear panel DDT
™
switch
2 front panel attenuators, rear panel
mode switch, rear panel DDT
™
switch
Indicator LEDs
2 DDT/clipping, 2 Status/Power,
2 Signal
2 DDT/clipping, 2 Status/Power,
2 Signal
Protection
Temp, DC, turn-on transients, subsonic,
improper load or shorts
Temp, DC, turn-on transients, subsonic,
improper load or shorts
Connectors
Combi XLR & 6.3 mm input, Speakon
®
and Binding Post speaker output, IEC
mains connector
Combi XLR & 6.3 mm input, Speakon
®
and Binding Post speaker output, IEC
mains connector
Construction
16 ga. steel with cast aluminum front
panel and steel grille
16 ga. steel with cast aluminum front
panel and steel grille
Dimensions
88.9 mm x 482.6 mm x 376.3 mm
+ 31.8 mm for rear support ears
and connectors
(3.5" x 19” x 14.81” + 1.25”)
(+1.5” for handle depth)
88.9 mm x 482.6 mm x 376.3 mm
+ 31.8 mm for rear support ears
and connectors
(3.5” x 19" x 14.81” + 1.25”)
(+ 1.5” for handle depth)
Gross Weight
36.3 lbs. (16.46 kg.) 41.6 lbs. (18.87 kg.)
Net Weight
32.7 lbs. (14.83 kg.) 36.3 lbs. (16.46 kg.)

Peavey CS 1200 Specifications

General

Channels	2
Signal to Noise Ratio	> 100 dB
Input Impedance	20k ohms balanced, 10k ohms unbalanced
Weight	35 lbs
Dimensions	3.5" H x 19" W x 15.25" D
