Peavey PV I 8B+ - Specifications; Power Output and Input Specs; Equalization and Protection; Dimensions and Weight

10
Output Power:
350 watts / 4 ohms, music power
220 watts / 8 ohms, music power
250 watts / 4 ohms, continuous
150 watts / 8 ohms, continuous
650 watts / 8 ohms, Bridged
Aux SEND Output:
-10 dBv nominal, 1k ohms
Tape REC Output:
-10 dBv nominal, 1k ohms
Input lmpedance:
Low-Z Mic: 1k ohms
High-Z Line: 10k ohms
Tape Input: 10k ohms
Input Channel Equalization:
Bass Control: 100 Hz
Mid Control: 2,500 Hz (or 2.5Khz)
Treble Control: 8,000 Hz (or 8kHz)
Master Graphic Equalization:
63 Hz: +/- 12 dB
160 Hz: +/- 12 dB
400 Hz: +/- 12 dB
2.5 kHz: +/- 12 dB
6.3 kHz: +/- 12 dB
16 kHz: +/- 12 dB
Protection Circuit:
Power on Mute delay time: 2 seconds
Power Consumption:
450 watts
Dimensions (HxWxD):
11.25 in. x 19 in. x 11.25 in.
28.6 cm x 48.3 cm x 28.6 cm
Weight:
39 lbs.
17.7 kg
PV
™
i 8B+
SPECIFICATIONS
Logo referenced in Directive 2002/96/EC Annex IV
(OJ(L)37/38,13.02.03 and defined in EN 50419: 2005
The bar is the symbol for marking of new waste and
is applied only to equipment manufactured after
13 August 2005
