15
PV
™
10, PV
™
14 & PV
™
20 Series Specications
Inputs
Function Input Z
(ohms min)
Input Gain
Setting Min** Nominal* Max
Bal/
Unbal
Connector
Microphone
(150 ohms)
2.2k Max Gain
(60 dB)
Min Gain
(10 dB)
-76 dBu
-24 dBu
-56 dBu
-4 dBu
-38 dBu
+14 dBu
Bal XLR Pin 1 Gnd
Pin 2 (+)
Pin 3 (-)
Line
(10 k ohms)
10k Max Gain
(40 dB)
Min Gain
(-10 dB)
-56 dBu
-10 dBu
-36 dBu
+14 dBu
-18 dBu
+32 dBu
Bal 1/4" TRS;
Tip (+)
Ring (-)
Sleeve Ground
Stereo Line
Input
10k Max Gain
(20 dB)
Nominal
-36 dBu
-21 dBu
-16 dBu
-1 dBu
+2 dBu
+17 dBu
Unbal 1/4" TS;
Tip (+)
Sleeve Ground
Tape 10k N/A
(10 dB)
-17 dBu -10 dBV +12 dBu Unbal RCA Phono
Input Levels
0 dBu=0.775 V (RMS)
** Min Input Level (sensitivity) is the smallest signal that will produce nominal output (+4 dBu) with channel and
master faders set for maximum gain.
* Nominal settings are dened as all controls set at 0 dB (or 50% rotation for rotary pots) except the gain adjustment
pot which is as specied.
Outputs
Function Min Load
Z
(ohms)
Nominal Max
Bal/
Unbal
Connector
Main Left/Right 600 +4 dBu +22 dBu Bal XLR Pin Ground Tip
Pin 2 (+), Pin 3 (-)
1/4" TRS: Tip (+), Ring (-)
Sleeve Ground
Effects and
Monitor Sends
600 +4 dBu +22 dBu Bal 1/4" TRS: Tip (+), Ring (-)
Sleeve Ground
Control Room 600 +4 dBu +22 dBu Bal 1/4" TRS: Tip (+), Ring (-)
Sleeve Ground
Headphone 8 +4 dBu
(no load) +22 dBu Unbal 1/4" TRS; Tip Left, Ring Right
Sleeve Ground
Tape 2.2k +4 dBu +22 dBu Unbal RCA Phono
USB
Output Levels
0 dBu=0.775 V (RMS)
Gain
Mic Input Gain Adjustment Range: 10 dB to 60 dB
Mic Input to Left/Right Balance Output 88 dB (max gain)
Line Input Gain Adjustment Range: -10 dB to 40 dB
Line Input to Left/Right Balance Output 60 dB (max gain)
Stereo Line Input Gain Adjustment Range: Off to +20 dB
Stereo Line Input to Left/Right Output 40 dB (max gain)
