20 Specifications
Frequency Response
Mic Input to Left/Right Output 14 Hz to 25 kHz +0 dB/-1 dB
Total Harmonic Distortion
<0.02% 20 Hz to 20 kHz Mic to Left/Right Output (10 Hz to 80 kHz BW)
<0.005% Typical (22 Hz to 22 kHz BW)
<0.0007% Mic Pre-amp Distortion
Hum and Noise
Output Residual Noise S/N Ratio (Ref: +4dBu) Test Conditions
Master Left/Right -97 dBu
-90 dBu
-83 dBu
101 dB
94 dB
87 dB
Master Fader Down, Channel Levels Down
Master Fader Nominal, Channel Levels Down
Master Fade Nominal, Channel Faders Nominal,
Panned Odd Channels (left), Even Channels (right)
Monitor Send -95 dBu
-80 dBu
99 dB
84 dB
All controls off
All channel sends nominal, masters nominal
Effects Sends -100 dBu
-80 dBu
104 dB
84 dB
All controls off
All channel sends nominal, masters nominal
(Hum and noise measurements: 22 Hz to 22 kHz BW)
Equivalent Input Noise (EIN)
-129 dBu (input terminated with 150 ohms)
Crosstalk/Attenuation
Adjacent Input Channels (1 kHz) >90 dB Mute Button Attenuation (1 kHz) >90 dB
Left to Right Outputs (1 kHz) >75 dB Channel Fader Kill (1 kHz) >85 dB
Common Mode Rejection Ratio (Mic Input)
50 dB minimum (20 Hz to 20 kHz)
70 dB typical @ 1 kHz
Meters
8 segment, peak reading (0 db = +4 dBu)
Signal/Overload Indicators
Red LED lights 3 dB below clipping
Dimensions
PV10: 12.125" wide x 14.75" deep x 3.5" high
(30.80cm x 37.47cm x 8.89cm)
PV20: 22.125" wide x 15.75" deep 3.5" high
(56.2cm x 40.0cm x 8.9xm)
PV14: 16.125" wide x 14.75" deep x 3.5" high
(40.96cm x 37.47cm x 8.89cm)
Installation Note:
This unit must have the following clearances from any combustible surface: top: 8", sides: 12", back: 12"
Weight
Power Requirements
PV10: 100-240 VAC 50/60 Hz 13 Watts
PV14: 100-240 VAC 50/60 Hz 17 Watts
PV20: 100-240 VAC 50/60 Hz 27 Watts
PV10: 9.3 lbs. (4.22 kg)
PV14: 12.1 lbs (5.49kg)
PV20: 16.3 lbs. (7.39kg)
