Page #19 background imageLoading...
Page #19 background image
17
VSP |
MOTOR CONFIG
FS 16
MODULE SWITCHING FREQUENCY
Sets the switching frequency of the power module.
Default 16 kHz Range 4-16 kHz Step 1 kHz
SELECT
CONF.SENS.PRE
Pressure transducer parameters setting
9
CONF.SENS.PRE
1 TYPE 4_20mA
FIRST PRESSURE TRANSDUCER
Select the pressure transducer type:
– 4–20 mA amperometric
– 0–10 V ratiometric
Default 4_20mA Range 4_20mA–0_10V Step
CONF.SENS.PRE
RANGE 16bar
FIRST PRESSURE TRANSDUCER RANGE
Select the maximum operating pressure of the pressure transducer.
Default 10 bar Range 10-16–20–40 bar Step
CONF.SENS.PRE
2 TYPE 4_20mA
SECOND PRESSURE TRANSDUCER
Select the pressure transducer type:
– 4–20 mA amperometric
– 0–10 V ratiometric
Default 4_20mA Range 4_20mA–0_10V Step
CONF.SENS.PRE
RANGE 16bar
SECOND PRESSURE TRANSDUCER RANGE
Select the maximum operating pressure of the pressure transducer.
Default 10 bar Range 10-16–20–40 bar Step
CONF.SENS.PRE
MODE
ANALOGUE INPUTS MODE
Select the analogue input type you want to use for the pressure trans-
ducer.
NO_PREX (No selected analogue, the pump will always go the max-
imum frequency)
AN1 (First analogue input selected, see terminal board diagram)
AN2 (Second analogue input selected see terminal board diagram)
AN1+AN2 (Selected the total of the two analogue inputs see terminal
board diagram).
Default NO_PREX Range NO_PREX–AN1–AN2–AN1+AN2
