18
| VSP
SELECT
INOUT CONFIG.
Inputs and outputs type setting
9
INOUT CONFIG.
IN1 OFF
FIRST EXTERNAL INPUT (IN1)
Conguration and choice of use mode rst external input.
OFF = Disabled input
FLUX = External minimum ow sensor.
If this function is enabled, the VSP will be capable of
determining dry running after the time set in "T DRY"
(see
BASIC CONFIG
T DRY 10
)
EXT START = Start for external command
Default OFF Range OFF–FLUX–EXT START
INOUT CONFIG.
TYPE IN1
FIRST INPUT CONTACT TYPE
Choice of clean contact type to use in rst input (N.O. or N.C.)
Default N.O. Range N.O.–N.C.
INOUT CONFIG.
IN2 OFF
EXTERNAL SECOND INPUT (IN2)
Conguration and choice of use mode second external input.
OFF = Disabled input
SET POINT 2 = Second SET pressure of the system
Default OFF Range OFF– SET POINT 2
INOUT CONFIG.
TYPE IN2
SECOND INPUT CONTACT TYPE
Choice of clean contact type to use in second input (N.O. or N.C.)
Default N.O. Range N.O.–N.C.
INOUT CONFIG.
IN3 OFF
THIRD EXTERNAL INPUT (IN3)
Conguration and choice of use mode third external input.
OFF = Disabled input
EXT ALARM = External alarm
EXT START = Start for external command
Default OFF Range OFF–EXT ALARM–EXT START
INOUT CONFIG.
TYPE IN3
THIRD INPUT CONTACT TYPE
Choice of clean contact type to use in third input (N.O. or N.C.)
Default N.O. Range N.O.–N.C.
INOUT CONFIG.
OUT1 OFF
FIRST EXTERNAL OUTPUT
Enable or disable the output from relay (NO/NC)
OFF = Output disabled
RUN = VSP unit running
ERROR = VSP unit error
Default OFF Range OFF–RUN–ERROR
