PEDROLLO VSP User Manual

19
VSP |
INOUT CONFIG.
TYPE OUT1
FIRST OUTPUT CONTACT TYPE
• Choice of clean contact type to use in rst output (N.O. or N.C.)
Default N.O. Range N.O.–N.C.
INOUT CONFIG.
OUT2 OFF
SECOND EXTERNAL OUTPUT
• Enable or disable the output from relay (NO/NC)
OFF = Output disabled
RUN = VSP unit running
ERROR = VSP unit error
Default OFF Range OFF–RUN–ERROR
INOUT CONFIG.
TYPE OUT2
SECOND OUTPUT CONTACT TYPE
• Choice of clean contact type to use in rst output (N.O. or N.C.)
Default N.O. Range N.O.–N.C.

SELECT
CONF.GROUP
• PUMPS PARALLEL UNIT conguration mode
9
CONF. VEHICLE
MODE:SINGOLO
VSP OPERATING MODES
• Conguration and choice of VSP use mode single or parallel. If you
choose parallel operation, set the VSP in MASTER or SLAVE mode.
SINGLE= use single VSP
MASTER= use of VSP in MASTER mode that controls the second VSP in
SLAVE mode
SLAVE = use of VSP in SLAVE mode which is controlled by the second
VSP in MASTER mode
Default SINGOLO Range SINGOLO–MASTER–SLAVE
CONF.GROUP
TYPE: V+F
TYPE OF PARALLEL VSP OPERATION
• Conguration and choice of VSP parallel operating mode
V+F= alternating between VSP. If the rst VSP cannot meet the re-
quest, the second VSP starts which is modulated while the rst
always stays at maximum frequency.
V+V= alternating between VSP. If the rst VSP cannot meet the re-
quest, the second VSP starts and both are modulated in fre-
quency.
Default V+F Range V+F – V+V
Continued
