LEVEL 1 PROGRAMMING (User level)
To gain access to the Level 1 configuration menu proceed as follows:
1. Press the (t) and (u) keys simultaneously and keep them pressed for a few seconds
until the first programming variable appears on the display.
2. Release the (t) and (u) keys.
3. Select the variable to be modified using the (t) or (u) key.
4. When the variable has been selected it is possible:
• to display the setting by pressing SET key
• to modify the setting by pressing the SET key together with the (t) or (u) key.
When configuration values have been set you can exit the menu by pressing the (t) and
(u) keys simultaneously for a few seconds until the cold room temperature reappears.
5. The new settings are saved automatically when you exit the configuration menu.
LIST OF LEVEL 1 VARIABLES (User level)
VARIABLES MEANING VALUE DEFAULT
r0
Temperature difference compared to main SETPOINT 0.2 - 10 °C 2°C
d0
Defrost interval (hours) 0 - 24 hours 4 hours
d2
End-of-defrost setpoint.
Defrost is not executed if the temperature read by the
defrost sensor is greater than d2
(If the sensor is faulty defrosting is timed)
-35 - 45 °C 15°C
d3
Max defrost duration (minutes) 1 - 240 min 25 min
d7
Drip duration (minutes)
At the end of defrost the compressor and fans remain at
standstill for time d7, the defrost LED on the front panel
flashes.
0 - 10 min 0 min
F5
Fan pause after defrost (minutes)
Allows fans to be kept at standstill for a time F5 after
dripping. This time begins at the end of dripping. If no
dripping has been set the fan pause starts directly at the end
of defrost.
0 - 10 min 0 min
A1
Minimum temperature alarm
Allows user to define a minimum temperature for the room
being refrigerated. Below value A1 an alarm trips: the alarm
LED flashes, displayed temperature flashes and the buzzer
sounds to indicate the problem.
- -45°C
A2
Maximum temperature alarm
Allows user to define a maximum temperature for the room
being refrigerated. Above value A2 an alarm trips: the alarm
LED flashes, displayed temperature flashes and the buzzer
sounds to indicate the problem.
- +45°C
tEu
Evaporator sensor temperature display
(displays nothing if dE =1)
temperature read only
CHAP. 5 – Parameter programming
5.7
5.8
