ECP200 EXPERT
Pag. 8
USE AND MAINTENANCE MANUAL
Rev. 01-11
TECHNICAL CHARACTERISTICS
Power supply
Voltage
230 V~ ± 10% 50Hz / 60Hz
Max power (only electronics) ~ 7 VA
Rated current
(With all loads connected)
16A
Cold room conditions
Working temperature -5 ÷ +50°C
Storage temperature -10 ÷ +70°C
Relative humidity Less than 90%
General characteristics
Type of sensors that can be connected NTC 10K 1%
Resolution 0,1 °C.
Sensor read precision ± 0,5 °C
Read range -45 ÷ +45 °C
Output characteristics
Description Installed relay Card output characteristics Note
Compressor
(Relay 30A AC1)
10A 250V
~ (AC3) (2HP)
(100000 cycles)
Elements
(Relay 30A AC1)
16A 250V
~ (AC1)
Fans
(Relay 16A AC1)
2,7A 250V
~ (AC3)
Room light
(Relay 16A AC1)
16A 250V
~ (AC1)
The sum of
contemporary
absorptions of these
outputs has not to
exceed 16A
Alarm / Aux (non-
powered contact)
(Relay 8A AC1)
8(3)A 250V
~
General electrical protection
Differential magnetothermic circuit breaker 16A
Id=300 mA
(Id=30 mA on request)
Disconnecting power 4.5 kA
Dimensional characteristics
Dimensions 16.8cm x 9.7cm x 26.2cm (HxPxL)
Insulation / mechanical characteristics
Box protection rating IP65
Box material ABS autoestinguente
Type of insulation Class II
CHAP. 4 - Technical characteristics
