MANUALE D’USO E MANUTENZIONE
DISPLAY LCD
1. Ambient temperature / parameters
2. Evaporator 1 temperature / Evaporator 2 temperature / day of current month (see
setting on parameter tEu on 1
st
level programming) / parameters (during
programming)
3. System status / time / parameter values:
a. C1 = compressor 1 active
b. C2 = compressor 2 active
c. d1 = evaporator 1 defrosting
d. d2 = evaporator 2 defrosting
e. Current time
f. Time parameters
4. Programming (control is in programming mode)
5. Cold (compressor call indicator)
6. Defrost
7. Fans (flashing during fan stop – parameter F5)
8. Light
9. Alarm
10. Stand-by (flashing in stand-by. Outputs deactivated.)
CHAP. 5 - Parameter programming
5.3
n
p
q r s
o
t u v w
