Pego PLUS 200 2 PLT User Manual

PLUS 200 2 PLT
Page 14
Rev. 02-06
MANUALE D’USO E MANUTENZIONE
LEVEL 1 PROGRAMMING (User level)
To gain access to the Level 1 configuration menu proceed as follows:
1. Press the (t) and (u) keys simultaneously and keep them pressed for a few seconds
until the first programming variable appears on the display.
2. Release the (t) and (u) keys.
3. Select the variable to be modified using the (t) or (u) key.
4. When the variable has been selected it is possible:
• to display the setting by pressing SET
• to modify the setting by pressing the SET key and the (t) or (u) keys.
When configuration values have been set you can exit the menu by pressing the (t) and
(u) keys simultaneously for a few seconds until the cold room temperature reappears.
5. The new settings are saved automatically when you exit the configuration menu.
CHAP. 5 - Parameter programming
