PLUS 200 2 PLT
Page 8
Rev. 02-06
MANUALE D’USO E MANUTENZIONE
TECHNICAL CHARACTERISTICS
Power supply
Voltage
230 V~ ± 10% 50 Hz
Max. power absorption ~ 7 VA
Climatic conditions
Working temperature -10 - 60°C
Storage temperature -30 - 70°C
Relative humidity Below 90% RH
General characteristics
Type of sensors that can be connected NTC 10K 1%
Resolution 1°C
Sensor read precision ± 0.5°C
Read range -45…+45 °C
PLUS200 2 PLT - Output characteristics - max applicable load (230 V AC)
Compressor (non-powered contact) 750W (AC3)
Elements (non-powered contact) 1500W (AC1)
Fans (non-powered contact) 500W (AC3)
Room light (non-powered contact) 800W (AC1)
Alarm contact 800W (AC1)
Dimensional characteristics
Dimensions 19.3 cm x 7.9 cm x 20.3 cm (HxPxL)
Insulation / mechanical characteristics
Box protection rating IP65
Box material ABS self-extinguishing
Type of insulation Class II
CHAP. 4 – Technical characteristics
CHAPTER 4: TECHNICAL CHARACTERISTICS
