Pelpro PP130-B - Raw Test Data and Analysis

OMNI-Test Laboratories, Inc.
Pellet Heater Lab Data - ASTM E2779 / ASTM E2515
Manufacturer: Hearth & Home Equipment Numbers: 637, 283A, 592
Model: PP130B
Tracking No.: 2266
Project No.: 0135PS041E
Run #: 1
Date: 3/26/18
TRAIN 1 (First Hour emissions)
Sample Component Reagent Filter, Probe Weights
or Dish # Final, mg Tare, mg Particulate, mg
A. Front filter catch Filter D469 116.2 115.3 0.9
B. Rear filter catch Filter 0.0
C. Probe catch* Probe 0.0
D. Filter seals catch* Seals 0.0
Sub-Total
Total Particulate, mg: 0.9
TRAIN 1 (Remainder of Test)
Sample Component Reagent Filter, Probe Weights
or Dish # Final, mg Tare, mg Particulate, mg
A. Front filter catch Filter
D470
117.7
115.9
1.8
B. Rear filter catch Filter
D471
114.5
114.7
-0.2
C. Probe catch* Probe
29
114278.4
114278.3
0.1
D. Filter seals catch* Seals
R574
3294.7
3294.1
0.6
Sub-Total
Total Particulate, mg: 2.3
Train 1 Aggregate
Total Particulate, mg: 3.2
TRAIN 2
Sample Component Reagent Filter, Probe Weights
or Dish # Final, mg Tare, mg Particulate, mg
A. Front filter catch Filter
D472
119.3
116.4
2.9
B. Rear filter catch Filter
D473
116.2
116.2
0.0
C. Probe catch* Probe
30
114329.1
114329.2
0.0
D. Filter seals catch* Seals
R575
3381.4
3381.1
0.3
Total Particulate, mg: 3.2
AMBIENT
Sample Component Reagent Filter # or Weights
Probe # Final, mg Tare, mg Particulate, mg
A. Front filter catch* Filter 116.2 116.0 0.2
Total Particulate, mg: 0.2
Component Equations:
A. Front filter catch
Final (mg) - Tare (mg) = Particulate, mg
B. Rear filter catch
Final (mg) - Tare (mg) = Particulate, mg
C. Probe catch
Final (mg) - Tare (mg) = Particulate, mg
*Particulate catch that results in a negative number, is assumed to be zero for
probes and seals, negative numbers for filters are assumed to be part of the seal
weight.
Control No. P-SFDK-0003, Effective Date 5/6/16
File - 135PS041E PP130 Run 1, Tab - Gravimetric Analysis
22 of 112
