P266 Series Single-Phase Condenser Fan Speed Controls Installation Instructions 3
Mounting
Location Considerations
Observe these guidelines when locating and mounting
a P266 Series Single-Phase Condenser Fan Speed
Control:
• Ensure that the mounting surface and mounting
hardware can support the control and wiring.
• Mount the P266 Series Control upright on a vertical
surface with the heat sink fins oriented vertically
and the conduit/electrical holes facing down.
• Ensure that air can flow through the heat sink fins
and provide 10 cm (4 in.) minimum clearance
around the heat sink.
• Mount the P266 Series Control in a location away
from sources of excessive heat and within the
specified ambient operating conditions. See
Technical Specifications
for ambient operating
conditions.
Wiring
Refer to the model specific wiring diagram located on
the interior label of the P266 Series Single-Phase
Condenser Fan Speed Control, and observe these
guidelines when wiring the P266 Series Control:
• Ensure that the wires between the P266 Series
Control and the fan motor do not exceed 15 m
(50 ft).
• Wires connected to the line voltage terminal block
must be 3.31 mm
2
(12 AWG) or smaller.
• Low voltage wires must be less than 30 m (100 ft).
!
WARNING: Risk of Electric Shock.
Disconnect or isolate all power supplies
before making electrical connections.
More than one disconnection or isolation
may be required to completely
de-energize equipment. Contact with
components carrying hazardous voltage
can cause electric shock and may result
in severe personal injury or death.
AVERTISSEMENT : Risque de
décharge électrique.
Débrancher ou isoler toute alimentation
avant de réaliser un branchement
électrique. Plusieurs isolations et
débranchements sont peut-être
nécessaires pour -couper entièrement
l'alimentation de l'équipement. Tout
contact avec des composants
conducteurs de tensions dangereuses
risque d'entraîner une décharge
électrique et de provoquer des blessures
graves, voire mortelles.
IMPORTANT: Do not connect supply power to the
P266 Series Control before finishing wiring and
checking all wiring connections. Short circuits or
improperly connected wires can result in damage to
the P266 Series Control and void any warranty.
IMPORTANT: Do not exceed the P266 Series
Control electrical ratings. Exceeding P266 Series
Control electrical ratings can result in permanent
damage to the P266 Series Control and void any
warranty.
IMPORTANT: Use 60/75 C copper conductors only.
Make all wiring in accordance with local, national,
and regional regulations.
IMPORTANT: Electrostatic discharge can damage
P266 Series Control components. Use proper
Electrostatic Discharge (ESD) precautions during
installation and servicing to avoid damaging P266
Series Control components.
